HP 24EA User Manual

24-07-201
HP Restricted
Page 4
Step 2: Strip the screws from rear cover, then move rear cover follow the below way ,at last
remove deco
Step 3: To remove the shielding(contain the other material );
(3.1) Dismantle the rear cover supporter
(3.2) Pull out the LVDS/ LED FFCs to separate the base assembly from the unit;
(3.3) Remove the four screws to separate shielding from CB
Step 4: Strip the screws *9pcs
Remove the screws with
Screwdriver
Dismantle the rear cover first
from the two marked position
Remove the 8pin FFC from main
board then remove rear cover
