24-07-201

HP Restricted

Page 5

Step 3: To remove the shielding(contain the other material );

(3.1) Dismantle the rear cover supporter

(3.2) Pull out the LVDS/ LED FFCs to separate the base assembly from the unit;

(3.3) Remove the four screws to separate shielding from CB
