WEEE Report
Report No.: A2180169984101002 Page 4 of 19
5. Appearance of the Product
6. Disassembly Assessment
6.1 Disassembly Procedure
The product is disassembled into different parts and grouped by the type of material sharing common characteristic( such as plastic,
metal, glass) based on the treatment requirements as set out in the WEEE Directive, followed by the current state of the art of recycling
and recovery technology. In addition, the recycling is subject to the economic feasibility, disassembly tools, only bigger parts that can be
easily separated are included in the recycling and reuse calculation. Other parts, respectively materials that cannot be separated by e.g.
standard tools are classified as either unspecified materials or distributed to the relative waste fraction is expected with recovery rate.

HP 24m Specifications

General

3D	No
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LED
Viewable size, vertical	527 mm
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	296.4 mm
Digital vertical frequency	- Hz
Digital horizontal frequency	- kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
AC input voltage	100 - 240 V
Power consumption (max)	25 W
Power consumption (standby)	0.3 W
Power consumption (typical)	22 W
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI, VGA
Package depth	142 mm
Package width	610 mm
Package height	410 mm
Package weight	5000 g
HP segment	Home

Weight and Dimensions

Depth (with stand)	189 mm
Height (with stand)	419 mm
Weight (with stand)	2840 g
Depth (without stand)	37.5 mm
Width (without stand)	542.7 mm
Height (without stand)	330.5 mm
