EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
2.3 Flip the monitor over and disassemble the RC from left to right
3.Remove ASSY SHD & PCBA
3.1 Remove fabric conductive*2 , acetic tapes*2 , CTRL BD FFC & LVDS FFC
