HP 2510-24 User Manual

2 – Index
Index
Clear button
deleting passwords … 1-5
description … 1-5
location on switch … 1-2, 1-5
restoring factory default configuration … 1-5,
4-11
to delete password protection … 3-4
CLI prompt, console
displaying … 2-18
configuration
checking when troubleshooting … 4-3
DHCP/Bootp … 3-2
full duplex only for mini-GBICs … 2-7
IP address … 3-3
IP address, manually … 3-2
manager password … 3-2
restoring factory defaults … 1-5, 4-11
subnet mask … 3-3
Switch Setup screen … 3-2
connecting the switch to a power source … 2-15
connector specifications … A-2
console
checking messages during
troubleshooting … 4-9
displaying the CLI prompt … 2-18
features … 2-17
how to connect in-band … 2-17
how to connect out-of-band … 2-17
serial cable connection … 2-18
Switch Setup screen … 3-2
Telnet access … 3-5
terminal configuration … 2-17
console port
location on switch … 1-2
cross-over cable
pin-out … B-7
D
deleting passwords … 1-5
description
back of switch … 1-6
front of switch … 1-2
LEDs … 1-3
switch … 1-1
desktop switch
sample topology … 2-19
DHCP
automatic switch configuration … 3-2
for in-band access … 2-17
diagnostic tests … 4-9
checking the console messages … 4-9
checking the LEDs … 4-9
end-to-end connectivity … 4-10
testing the switch only … 4-9
testing twisted-pair cabling … 4-10
downloading new switch software … 4-12
dual-personality ports
location on switch … 1-2
operation description … 1-2
E
electrical specifications, switch … A-1
EMC regulatory statements … C-8
environmental specifications, switch … A-1
F
factory default configuration, restoring … 4-11
factory default configuration,restoring … 1-5
Fault LED … 1-3
behavior during self test … 2-10
behaviors … 1-3
blinking definition … 1-4
location on switch … 1-2
showing error conditions … 4-4
FDx LED … 1-4–1-5
features
console … 2-17
switch … 1-7
fiber-optic cables … B-2
1000Base-LH … B-2
1000Base-LX … B-2
1000Base-SX … B-2
front of switch … 1-2
10/100/1000Base-TX ports … 1-2
Clear button … 1-5
description … 1-2
dual-personality ports … 1-2
LED Mode select button and LEDs … 1-4
LEDs … 1-3
network ports … 1-2
Reset button … 1-5

HP 2510-24 Specifications

General

Switching Capacity	8.8 Gbps
Layer	Layer 2
Jumbo Frame Support	Yes
Ports	24 x 10/100
Management	Web-managed
Operating Temperature	0°C to 45°C
Weight	3.08 kg
