Index – 3
Index
full-duplex fixed configuration
effects on network connections … 4-1
full-duplex operation of mini-GBICs … 2-7
H
horizontal surface
mounting switch on … 2-14
I
in-band … 3-1
in-band console access
types of … 2-17
included parts … 2-1
installation
connecting the switch to a power source … 2-15
horizontal surface mounting … 2-14
location considerations … 2-6
network cable requirements … 2-5
precautions … 2-4
rack or cabinet mounting … 2-11
site preparation … 2-5
summary of steps … 2-3
wall mounting … 2-15
IP address
configuring … 3-3
L
LED Mode
indicator LEDs … 1-4
select button … 1-4
selecting the display … 1-4
LEDs
Act … 1-4
act … 1-4
behavior during self test … 2-10
blinking definition … 1-4
checking during troubleshooting … 4-9
descriptions of … 1-3
error indications … 4-4
Fault … 1-3
behavior during self test … 2-10
showing error conditions … 4-4
FDx … 1-4–1-5
LED Mode View select indicators … 1-4
Link … 1-3
link … 1-4
location on switch … 1-2
Mode
selecting the display … 1-4
on switch … 1-3
port
description … 1-3
Power … 1-3
behavior during self test … 2-10
Self Test … 1-3
behavior during self test … 2-10
Spd … 1-4–1-5
length limitations
1000Base-LH connections … 2-6
1000Base-LX connections … 2-6
1000Base-SX connections … 2-6
1000Base-T connections … 2-5
link LED … 1-4
Link LEDs … 1-3
link test … 4-10
location for the switch, considerations … 2-6
M
MDIX
feature description … B-5
MDI-X to MDI network cable … B-6
MDI-X to MDI-X network cable … B-7
mini-GBICs
full-duplex operation … 2-7
slot, location on switch … 1-2
mounting the switch
in a rack or cabinet … 2-11
precautions … 2-4
on a horizontal surface … 2-14
on a wall … 2-15

HP 2510-24 Specifications

General

Switching Capacity	8.8 Gbps
Layer	Layer 2
Jumbo Frame Support	Yes
Ports	24 x 10/100
Management	Web-managed
Operating Temperature	0°C to 45°C
Weight	3.08 kg
