HP 2520 Series User Manual

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP 2520-8-PoE Switch J9137A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-24-PoE Switch J9138A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-8G-PoE Switch J9298A
8 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143A
Note 2 Localization required. (See Localization Menu for list.)
Factory Racked Models
HP 2520-24-PoE Switch J9138A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-8G-PoE Switch J9298A
QuickSpecs
HP 2520 Switch Series
Configuration
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 5

HP 2520 Series Specifications

General

Ports	8/24
Layer	Layer 2
Management	SNMP
PoE	Available on some models (2520-8-PoE, 2520-24-PoE)
Jumbo Frame Support	Yes
Model	HP 2520 Series
