HP 2530-24G User Manual

1-1
1
Introducing the Switch
The HP 2530 Switch Series are multiport switches that can be used to build
high-performance switched workgroup networks. These switches are store-
and-forward devices that offer low latency for high-speed networking. Six of
the switches also support the IEEE 802.3at standard for providing PoE+ power
to connected devices.
HP 2530-8 Switch (J9783A)
HP 2530-24 Switch (J9782A)
HP 2530-48 Switch (J9781A)
HP 2530-8G Switch (J9777A)
HP 2530-24G Switch (J9776A)

HP 2530-24G Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Power Supply	Internal
MAC Address Table	16, 000 entries
Input Voltage	100-240 VAC
Mounting	Rack-mountable
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	15% to 95% non-condensing
Ports	24 RJ-45 autosensing 10/100/1000 ports
Uplink Ports	4 x SFP
Layer	Layer 2
Management	SNMP
Weight	2.7 kg
Memory and Processor	128 MB flash
