Additional Information on Arbitrary Waveforms
• Press the Arb key to output the arbitrary waveform currently
selected (to scroll through the waveform choices and make a
selection, press
Arb List ).
• In addition to creating a new arbitrary waveform from the front
panel, you can also edit any existing user-defined waveforms. You can
edit waveforms created either from the front panel or from the
remote interface. However, you cannot edit any of the five built-in
arbitrary waveforms.
Use the “
GET” option under the NEW ARB command in the EDIT MENU
to load an existing user-defined waveform. Then, use the LINE EDIT,
POINT EDIT, and INVERT commands to edit the waveform.
• The
INVERT command in the EDIT MENU takes the inverse of each
point in the specified waveform by changing the sign.
• You can use the
DELETE command in the EDIT MENU to delete any
user-defined waveforms in volatile memory. A list of all user-defined
waveforms appears when you move to the
DELETE command.
Chapter 3 Features and Functions
Arbitrary Waveforms
108
