3-12

Virus Throttling (Connection-Rate Filtering)

Configuring Connection-Rate Filtering

Example of a Basic Connection-Rate Filtering Configuration

Figure 3-2. Sample Network

Basic Configuration. Suppose that in the sample network, the administra-

tor wanted to enable connection-rate filtering and configure the following

response to high connection-rate traffic on the switch:

■ Ports B1 - B3: Throttle traffic from the transmitting host(s).

■ Port B4: Respond with Notify-Only to identify the transmitting

host(s).

■ Ports B9, D1, and D2: Block traffic from the transmitting host(s).

Figure 3-3 illustrates the configuration steps and resulting startup-config file.

HP Switch

Server

Company

Intranet

VLAN 1

15.45.100.1

VLAN 10

15.45.200.1

Server

VLAN 15

15.45.300.1

Switch

Server

Switch
