10-104

IPv4 Access Control Lists (ACLs)

Displaying ACL Configuration Data

Figure 10-36. Example of Listing an IPv6 ACL

HP Switch(config)# show access-list Accounting

Access Control Lists

Name: Accounting

Type: ipv6

Applied: Yes

SEQ Entry

-----------------------------------------------------------------------

10 Action: permit

Remark: Telnet Allowed

Src IP: 2001:db8:0:1af::10:14 Prefix Len: 128

Dst IP: :: Prefix Len: 0

Src Port(s): Dst Port(s): eq 23

Proto : TCP Option(s):

Dscp : -

20 Action: permit

Src IP: 2001:db8:0:1af::10:23 Prefix Len: 128

Dst IP: :: Prefix Len: 0

Src Port(s): Dst Port(s): eq 23

Proto : TCP Option(s):

Dscp : -

30 Action: deny (log)

Src IP: 2001:db8:0:1af::10 Prefix Len: 116

Dst IP: :: Prefix Len: 0

Src Port(s): Dst Port(s):

Proto : TCP Option(s):

Dscp : -

40 Action: permit

Src IP: 2001:db8:0:1af::10 Prefix Len: 116

Dst IP: :: Prefix Len: 0

Src Port(s): Dst Port(s):

Proto : IPV6

Dscp : -

Indicates whether the ACL

is applied to an interface.

TCP Source Port

Source Address

Protocol Data

Destination Address

Source and Destination

Prefix Lengths

TCP Destination Port

DSCP Codepoint or Precedence

Note: An empty TCP field indicates

that the TCP port number for that

field can be any value.

Remark Field (Appears if remark configured.)
