HP 3500yl Series User Manual

10-120
IPv4 Access Control Lists (ACLs)
Enable ACL “Deny” Logging
Figure 10-47. Example of IPv6 ACL Performance Monitoring Output
Figure 10-48 shows a sample of performance monitoring output for an IPv4
ACL assigned as a VACL.
Figure 10-48. Example of IPv4 ACL Performance Monitoring Output
HP Switch# show statistics aclv6 V6-02 vlan 20 vlan
HitCounts for ACL V6-02
Total
( 5) 10 permit icmp ::/0 fe80::20:2/128 128
( 4) 20 permit icmp ::/0 fe80::20:3/128 128
( 136) 30 permit tcp fe80::20:1/128 ::/0 eq 23
( 2) 40 deny icmp ::/0 fe80::20:1/128 128
( 10) 50 deny tcp ::/0 ::/0 eq 23
( 8) 60 deny icmp ::/0 ::/0 133
( 155) 70 permit ipv6 ::/0 ::/0
HP Switch# sho statistics aclv4 102 vlan 20 vlan
HitCounts for ACL 102
Total
( 1) 10 permit icmp 10.10.20.3 0.0.0.0 10.10.20.2 0.0.0.0 8
( 2) 20 deny icmp 10.10.20.3 0.0.0.0 10.10.20.1 0.0.0.0 8 log
( 2) 30 deny icmp 10.10.20.2 0.0.0.0 10.10.20.3 0.0.0.0 8 log
( 1) 40 deny icmp 10.10.20.2 0.0.0.0 10.10.20.1 0.0.0.0 8 log
( 10) 50 deny tcp 10.10.20.2 0.0.0.255 10.10.20.3 0.0.0.255 eq 23 log
( 27) 60 permit ip 0.0.0.0 255.255.255.255 0.0.0.0 255.255.255.255

HP 3500yl Series Specifications

General

Input Voltage	100-240 VAC
Ports	24/48 x 10/100/1000 ports (depending on model)
Uplink Ports	4 x SFP ports
Layer	Layer 3
Management	CLI, Web, SNMP
Routing Protocol	RIP, OSPF, BGP
Operating Temperature	0°C to 45°C
Stacking	Yes
Memory	512 MB
VLAN Support	Yes
Layer 3 Routing	Yes
Security Features	ACLs, 802.1X
Power Supply	Internal
Power over Ethernet (PoE)	Optional
