12-13

Traffic/Security Filters and Monitors

Filter Types and Operation

The following revisions to the named source-port filter definitions maintain

the desired network traffic management, as shown in the Action column of the

show command.

Figure 12-11. Example Showing Network Traffic Management with Source Port Filters

We next apply the updated named source-port filters to the appropriate switch

ports. As a port can only have one source-port filter (named or not named),

before applying the new named source-port filters we first remove the existing

source-port filters on the port.

The named source-port filters now manage traffic on the switch ports as

shown below, using the show filter source-port command.

HP Switch(config)# filter source-port named-filter accounting forward 8,12,13

HP Switch(config)# filter source-port named-filter no-incoming-web drop 8,12,13

HP Switch(config)#

HP Switch(config)# show filter source-port

Traffic/Security Filters

Filter Name | Port List | Action

-------------------- + -------------------- + ----------------------

web-only | 2-6,8-9,12-26 | drop 2-26

accounting | 7,10-11 | drop 1-6,9,14-26

no-incoming-web | 1 | drop 7-8,10-13

HP Switch(config)#

HP Switch(config)# no filter source-port 8,12,13

HP Switch(config)# filter source-port 8,12,13 named-filter accounting

HP Switch(config)#
