HP 3500yl Series User Manual

12-23
Traffic/Security Filters and Monitors
Configuring Traffic/Security Filters
Figure 12-16. Example of Displaying Filter Data
HP Switch(config)# show filter
Traffic/Security Filters
IDX Filter Type | Value
--- ------------ + --------------
1 Source Port | A1
2 Source Port | A2
3 Multicast | 010000-123456
4 Multicast | 010000-224466
5 Protocol | Appletalk
6 Protocol | ARP
HP Switch(config)# show filter 4
Traffic/Security Filters
Filter Type : Multicast
Multi-cast Addres : 010000-224466
Dest Port Type | Action
--------- --------- + -------
A1 1000LX | Forward
A2 | Forward
A3 | Forward
A4 1000SX | Forward
B1 100/1000T | Drop
B2 100/1000T | Drop
B3 100/1000T | Drop
B4 100/1000T | Drop
C1 10/100TX | Forward
C2 10/100TX | Forward
C3 10/100TX | Forward
. . .
Filter Index Numbers
(Automatically Assigned)
Lists all filters configured
in the switch.
Uses the index number
(IDX) for a specific filter
to list the details for that
filter only.
Criteria for Individual
Filters

HP 3500yl Series Specifications

General

Input Voltage	100-240 VAC
Ports	24/48 x 10/100/1000 ports (depending on model)
Uplink Ports	4 x SFP ports
Layer	Layer 3
Management	CLI, Web, SNMP
Routing Protocol	RIP, OSPF, BGP
Operating Temperature	0°C to 45°C
Stacking	Yes
Memory	512 MB
VLAN Support	Yes
Layer 3 Routing	Yes
Security Features	ACLs, 802.1X
Power Supply	Internal
Power over Ethernet (PoE)	Optional
