Section
VI
Channels condition
the
input
signals,
lurnish
square-wave
outputs
that are
used for
phase
tneasurements
and
produce
logarithrnic
outputs that are used for amplitude rneasure-
ments.
Thc
logarithmic outputs are
applied dircctly to the
Furution
Switching
circuits where they re individually
selected
(Log
A or LoB B) or sumned
(I-og
B/A) and
applied
to the
Output Filter
and
Panel Nleter i[ the
A,'npltude Display mode. The square-wave outputs arc
used
to
control J-K
flip-flops in the
Phase Detector which
provides
a dc
output voltage
proportional
to the
phase
difference
between
tbe two input signals. This
dc output is
coupled
tfuough
the l-'unction Switching
cftcuits aDd
Output Fi.lter to the
Panel llleter
and
Phase
Colrtrol
Logic
in the
Pluse
Display
mode.
The
Phase
Control
Logic senses
the magnitude ard
polarity
of the
phase
output
voltage
and,
in
turn, applics
dc offsets to the Phase Detertor to
maintair
a corre,ot
phase
reading.
Thc Dgital
Panel Meter is
a dc diSital voltmeter which corverts the analog
tunplitude
or
phase
informalion to a 3 1/2 digit 7 segnrent bar matrix,
48. F
UNCTIO
NAL
DESCRIPTION.
4-9.
lnput
Channels.
410. Refer to the Furctional Block
Diagram
(Figurc
7-l).
Since
the two
input channels are ideltical, the
following
discussion applies to both
channels.
4-1
l. Each
Input Channel is comprised of an
lnput
Attetruator, a Preanrplifier, a l,og A:nplifier, a Synchronous
Rectifier
and
a Level Tlanslator. The llput Attenuator
is
controlled
by the
lront
panel
voltage range
switch
and
provides
either
0 dB
(0.2
mV to 2 V range) or 20
dB (2 mV
to 20
V range) of attenuation.
The
Preamplifier
provides
Unity
gain
and iinpedance conversiol between the Input
Attenuator and thc input
of the
Log Arnplifier.
The Log
Amplifier oonverts
the input le\,el to a logarithmic
value,
supplies a li,nited signal to the Level
'franslator
a|d
furnishes
a
logarithmic output which is applied to the
Synchronous
Rectifier. The
Level Translator
corlditiolrs the
applied
signal and
produces
two square-wave
outputs that
are equal in amplitude and 180 degrees out
of
phase.
These
square-wave outputs
(desigiuted
A, A', B and
B') arc
applied directly
to the Phase Detector ctcuitry. The
logaritfunij output
from
the Log Anrplifier is
lull-rvave
rectified
in the Synchronous Rertifier
and
is applied to
the
Function
Switching
Assembiy
(A8) lor
use in the Ampti-
tud
e
Display
mode.
4-12. lnput
Attenuator
(A1lA2
R5. R6
Schematic
No.
l). Refer to Figure
7-l
and
Schenlatic
No. I for
the
following
discussion.
4"13.
The
lnput
Attenuator seryes as an
input voltage
divider and coupling network between
the input connector
and the input of the heamplifier. With the
front panel
range switch
set
to the 0.2 mV
to 2
V
position,
relay K1 is
energized, K2
is deenergzed and
the
input signal is coupled
directly tlrrough
Cl
to the Prearnplifier.
When
the 2 mV to
20
V range
is selectcd,
Kl is dcenergizcd, K2 is encrgized
and
the input signal
is
attenuated by 20dB
by
the 10:1
Model 3575A
divider network consisting ol
R5, R6 and associated
ctcuitry.
The attenuator flalness and input
shunt capaci-
tance
(<
30
pF)
is maintained by compcnsating
capacitors
C2
and C3. The circuit configuration and capacitor values
are s.rch that the input capacitance remains
constant
regardless of the voltage
range setting. Potentiometcrs
AlR4 and A2R.l are adjusted
for
rnininum
phasc
shift
between
channels at 13 MIIz and have
littlc
effect at lorvcr
frequencies.
4-14. Preamplifier
\A1lA2
a3 through 07
Schematic
No.
1). The Preampliliei is a iow noise. high input impedance
arnplifier circuit
which
provides
inpcdance
conversi()n
between
the Input Attenuator and the input of
the Log
Amplifier.
The
Preanrplifier is
comprised of an inpur
anplifier
stage
(Q3),
a differential driver stagc
(Qa,
Q5).
a
colnplenrentary-symmctr) output stage
(Q(r,
Q7)
and ar
integralor
(lC1).
The input arnplifier is
a
low noise
field-effect
transistor
which. havilg
a high inpul impedanre.
insures
a mi,rinum loading effelt on
thc
input
signal. The
input
circuit is
protected
against ovcrloads b) lilDilins
resistor R36.
The complenlentary-symrnetry output staga
provides
a
low output
impedance and supplies the
power
required
to drive the following
llg Amplifier sraBes.
Overall
gain,
stability
and linearity is
maintaited bi
negativc feedback fror
the
junction
of R19 and
RlO
through
the
parallel
network comprised
of Ll and lll: to
the
source of FET
Q3.
Due lo the
parallel
L/R
network
(Ll,
R2l) in the feedback
path,
thc
gain
of
the
preanrpLiti!'r
increases
with
frequency.
At
low
ftequencies. the reactanee
of
Ll is
very low,
the feedback is nearly
1007. and rhc
ltcamplifier
gain
is approximately l At high
frcclucncies
the rcactance of
Ll
increases. the
i'eedback
decreases
and
the
gain
approaches
l.l. The
reasoll for
this is lo
compensate for
high lrequency roLl-off in
the l-og Arnplilier
and associated circuitry.
Added stability
in
the Preanplitier
is
provided
by dc
feedback from
the
junction
of
Rl9 and
R20 tluough integrator ICI and the
htput Attenuator
nelwork to the
gate
of
Q3.
The
purpose
of tlris leedback
is
to mairtain
0 Vdc at the output of the Preamplifier.
4.15.
Overload Detector
(A1/A2
08 rhrough Ot0
Sche,
matic No. 1). The Preamplilier
output
signal at the
junction
of R22
and
R39 is reiitificd by
CR5,
filtered
bi'
Cl4 and
applied
to the base of
Q8.
When
the dc level
at
the
base of
QQ.
becomes
more
positive
than
2.6 Vdc
(2.2
V rns
input),
Q8
conducts.
QC)
cuts off and
Q10
is
forward
biased
tluough R26
arul R27. Transistor
Ql0
drives
the
corre-
sponding
overload
indicator (461/861)
on the Panel
Meter.
4'16.
Log Amplifier
(A3lA4
lC1 Schematic
No. 1). The
Log Arnplifier
(lCl)
is a hybrid circuit designed
specifically
for
usc
in the Model 35754.
This circuit converts
the input
amplitude
to a logarithmic value, furnishes
a
log
output
(lcl pins
l,
5,
and
9) for
amplitude measurements
and
produces
a
Iimited
output
(lC1 pir
12) that is used for
phase
measurements.
The
major
adyantage of the
Log
Amplificr is
that it
produces
usable outputs
over a dynamic
input range
of 80 dB.
