Table 21 Controller Node and Components
CSR TypeQty.DescriptionPart Number
Optional2SPS-Node Module 7200 NO HBA683245-001
Not4SPS-Node Module 7400 NO HBA683246-001
Not1 per nodeSPS-Node Boot Drive (Node drive)683248-001
Not1SPS-Adapter FC 4port683259-001
Not1SPS-Adapter CNA 2port683237-001
NotUp to 4 per nodeSPS-Module FC SFP468508–002
Figure 59 Internal Node Components
Figure 60 Internal Node Components
