7
Component Description
(1)
Joypad Press to open the OSD settings.
(2)
Security cable slot
Connects an optional security cable.
(3) Power connector Connects a power cord.
(4) HDMI port Connects the HDMI cable to a source device such as a computer.
(5) DisplayPort Connects a DisplayPort cable to a source device such as a computer.
(6) USB Type-C port (upstream)
Connects a USB Type-C cable to a source device, such as a computer. This USB Type-C
port can function as a DisplayPort audio/video input or as a USB Type-C 3.2 Gen 1
connection.
The USB Type-C port offers a faster transfer rate, and the alternate mode with DP1.4 supports the
maximum resolution of 1920 × 1080 @ 100 Hz (FHD model) or 2560 × 1440 @ 100 Hz
(QHD model). It can also be used to deliver up to 100 W of power to
a device. Power delivery outputs are 20 V/5 A, 15 V/5 A, 12 V/5 A, 9 V/3 A, 5 V/3 A to achieve a
100 W PD output.
Connecting a USB Type-C cable from a source device to this port on the monitor enables USB
ports on the monitor.
(7) DisplayPort OUT connector Connects the monitor to another monitor for multistreaming.
(8) RJ-45 (network) jack Network (RJ-45) data rate via USB Type-C max speed is 1000 Mbps.
● Green (left): The network is connected.
● Amber (right): Activity is occurring on the network.
NOTE: Supports Out-of-band Wake on Lan (WOL), Out-of-band Mac Address Passthrough
(MAPT), and PXE boot (HP models only). The functionality might vary with PC settings.
NOTE: This network port is fully energy efficient according to IEEE standards (IEEE
802.3az-2010), as long as all connected devices support this feature.
(9) USB Type-A port
Connects a USB cable to a peripheral device, such as a keyboard, mouse, or USB hard drive.
(10) USB Type-C port
(downstream)
Connects a USB Type-C cable to a peripheral USB device and provides data transfer, even when
the monitor is in Sleep mode or DC off with OSD Performance mode on. This port charges
most devices (up to 15 W), such as a smart phone or a tablet.
NOTE: Cables or adapters might be required (purchased separately).
(11)
USB Type-A port
USB port: Connects a USB device, provides data transfer, and (for select products) charges small
devices (such as a smartphone).
(12)
USB Type-A port with battery
fast-charging 1.2
Connects a USB cable to a peripheral device, such as a keyboard, mouse, or USB hard drive, and
charges peripheral devices.
USB port with battery fast-charging 1.2 (5 V × 1.5 A = 7.5 W): Connects a USB device,
provides high-speed data transfer, and charges small devices (such as a smartphone), even when
the monitor is DC off with OSD performance mode on.
NOTE:
Use a standard USB Type-A charging cable or cable adapter when charging a small
external device (purchased separately).
