Chapter 4 Retrofitting Options
To Retrofit A5 DC Power Input Assembly (Option 002)
4-4 Assembly-Level Service Guide
4
To Retrofit A5 DC Power Input Assembly
(Option 002)
Option 002 DC Power Input Assembly Parts
Item HP Part No. Qty.
• Chassis (MP10) 53131-00010 1
• A5 DC Power Input Assembly 53132-60206 1
• A4 AC Power Supply Assembly 53132-60207 1
• Rear label (MP11) 53131-80039 1
• TORX 10 screws (H2) 0515-0430 4
NOTE Option 002 can NOT be installed or combined with Option 060 Rear
Terminals.
Preliminary Procedure
1 Remove the cover.
See the section titled “To Remove the Cover” in Chapter 3 of this guide.
2 Remove the front bezel.
See the section titled “To Remove the Front Bezel” in Chapter 3 of this
guide.
3 Remove the existing A4 AC Power Supply Assembly.
4 Remove A1 Motherboard Assembly from chassis MP1.
See the section titled “To Remove A1 Motherboard Assembly” in
Chapter 3 of this guide.
