Chapter 6 Backdating
About the HP 53131A Calibration Menu
Assembly-Level Service Guide 6-9
6
CHANGE 1 (Firmware Revisions 3317, 3335, 3402, 3427)
(Continued)
The HP 53131A Utility/Calibration Menu Tree
NOTE
Turn power off, press and hold Recall (Utility) key, then press POWER
key to access this menu.
*
Timebase can be automatically calibrated only if the timebase option is installed.
HP-IB: 3
REV: XXXX
Recall
Utility
On / Stby
POWER
TIMEBAS: AUTO
TIMEBAS: INT
TIMEBAS: EXT
CAL: OFFS 2?
CAL: GAIN 2?
CAL: OFFS 1?
CAL: GAIN 1?
CAL:TIMEBAS?
CAL:TI 1 2?
TEST LOOP: ON
TEST LOOP: OFF
TST PRINT: ON
TST PRINT:OFF
BAUD: 19200
BAUD: 1200
BAUD: 9600
BAUD: 300
BAUD: 2400
PARITY: OFF
PARITY: EVEN
PARITY: ODD
SW PACE: NONE
SW PACE: XON
DTR: HIGH
DTR: LIMIT
DTR: HW PACE
SHOW 9 AS: 9,0
SHOW 9 AS: 9.0
*
TEST: DISP?
TEST: ALL?
TEST: ROM?
TEST: CPU?
TEST: HP-IB?
TEST: EEPROM?
TEST: FPGA?
TEST: QSPI?
TEST: FR END?
TEST: INTERP?
TEST: MEAS?
TEST: PRINT?
TEST: KEYPAD?
TEST: RAM?
To Next Page
