.HP
PART
NO
.
DESCRIPTION
14522A
Rack
Mounting
Tray
for
mounting
one
or
two
6235A
supplies
in
a
standard
19"
relay
rack.
1-16
INSTRUMENT
AND
MANUAL
IDENTIFICATION
1-17
Hewlett-Packard
power
supplies
are
identified
by
a
two
part
serial
number.
The
first
part
is
the
serial
number
prefix,
a
number-letter
combination
that
denotes
the
date
of
a
significant
design
change
and
the
country
of
manufac¬
ture.
The
first
two
digits
indicate
the
year
(10
=
1970,
11
=
1971,
etc.)
the
second
two
digits
indicate
the
week,
and
the
letter
A"
designates
the
U.
S.
A.
as
the
country
of
manufac¬
ture.
The
second
part
is
the
power
supply
serial
number.
A
different
sequential
number
is
assigned
to
each
power
sup¬
ply,
starting
with
00101.
1-18
If
the
serial
number
on
your
instrument
does
not
agree
with
those
on
the
title
page
of
the
manual,
Change
Sheets
supplied
with
the
manual
or
Manual
Backdating
Changes
define
the
difference
between
your
instrument
and
the
instrument
described
by
this
manual.
1-19
ORDERING
ADDITIONAL
MANUALS
1-20
One
manual
is
shipped
with
each
power
supply.
(Option
910
is
ordered
for
each
extra
manual,
see
paragraph
1-9.)
Additional
manuals
may
also
be
purchased
separately
from
your
local
Hewlett-Packard
field
office
(see
the
list
at
the
rear
of
this
manual
for
addresses).
Specify
the^model
number,
serial
number
prefix,
and
the
HP
Part
Number
pro¬
vided
on
the
title
page.
Table
1-1.
Specifications
and
Supplemental
Characteristics
SPECIFICATIONS:
The
following
specifications
describe
the
6235A's
warranted
performance
characteristics.
Source
Effect
(Line
Regulation);
Given
for
any
line
voltage
change
within
rating.
0
to
+6V
Output:
8m
V
DC
Output:
0
to
±18V
Outputs:
15mV
Voltage
span
over
which
output
may
be
varied
using
front
panel
controls.
*
Minimum
operating
voltage
for
each
output
is
<
50
millivolts.
PARD
(Ripple
and
Noise):
All
Outputs:
Less
than
1mV
rms
and
5mV
p-p
(20Hz
to
20MHz),
0
to
+6V
Output:
Maximum
rated
output
current
is
1
A.
Short
circuit
output
current
is
1.275
±15%
and
a
fixed
current
limit
circuit
limits
the
output
to
this
maximum
at
any
output
voltage
setting.
Load
Transient
Recovery
Time:
All
Outputs:
Less
than
50qsec
for
output
recovery
to
within
15m
V
of
nominal
output
voltage
following
a
load
change
from
a
full
load
to
half
load
(or
vice
versa).
0*
to
±18V
Output:
Maximum
rated
current
is
0.2A
for
each
output.
Short
circuit
output
current
is
0.255A
±15%
and
fixed
current
limit
circuits
limit
the
output
of
each
sup¬
ply
to
this
maximum
at
any
output
voltage
setting.
Unbal¬
anced
loads
within
current
rating
are
permitted.
Temperature
Ranges:
Operating
0
to
+40°C
ambient.
From
40°C
to
55°C,
out¬
put
current
is
derated
linearly
to
50%
at
55°C.
Storage:
-40°C
to
+75°C.
Meter
Ranges:
Input
Power:
Standard
Option:
104-127Vac
(120Vac
nominal),
47-
63Hz,
single
phase.
(240Vac
line
voltage
option
available,
see
paragraph
1-9.)
0
to
+6V
Output:
0
to
7V,
0
to
1,2A
0
to
+18V
Output:
0
to
21V,
0
to
0.24A
0
to
-18V
Output:
0
to
21V,
0
to
0.24A
Meter
Accuracy:
Load
Effect
(Load
Regulation):
Voltage
load
effect
is
given
for
a
load
current
change
equal
to
the
current
rating
of
the
supply.
0
to
+6V
Output:
8mV
0
to
±18V
Outputs:
lOmV
Voltmeter:
All
Outputs:
±3%
of
full
scale
Ammeter:
All
Outputs:
±4%
of
full
scale
Weight:
Net:
5
lb
(2.3
kg)
Shipping:
7
lb
(3.2
kg)
1-2
