HP 8100 - Elite Convertible Minitower PC - Page 78

4. Remove the four screws from the bottom of the hard drive carrier.
Figure 6-39 Removing the Security Screws
5. Slide the hard drive back to disconnect it from the carrier then lift it up and out of the carrier.
Figure 6-40 Removing the Hard Drive
68 Chapter 6 Removal and Replacement Procedures Convertible Minitower (CMT) Chassis
