HP 8562E Service Manual

Table 5-3. Replaceable Parts (continued)
Reference HP Part
C Qty
Description Mfr
Mfi Part
Designation
Number D
Code Number
AlAl 08562-60140 6 1 BD AY-KEYBOARD 28480 08562-6014C
AlAlWl 5062-8259 1 CABLE ASSEMBLY, RIBBON, 28480 5062-8259
KEYBOARD (AlAlJl to A3J602)
AlA 0960-0745 6 1 RPG ASSEMBLY (Includes Cable) 28480 0960-0745
AlWl 8120-8153 1 CABLE ASSEMBLY PROBE POWER/LED 28480 8120-8153
A2 08564-60010 1 CONTROLLER ASSEMBLY* 28480 08564-60010
A3 08563-60098 1 INTERFACE ASSEMBLY 28480 08563-60098
A4 08563-60076 1 LOG AMPLIFIER/CAL OSC. ASSY.* 28480 08563-60076
A5 08563-60023 5 1 IF FILTER ASSEMBLY 28480 08563-60023
A6 08564-60008 1 POWER SUPPLY ASSEMBLY* 28480 08564-60008
(Includes A6A2, does not include A6Al)
A6Al 5062-7089 6 1 HIGH VOLTAGE ASSEMBLY 28480 5062-7089
A6A2 08564-60009 1 REGULATOR BOARD ASSEMBLY 28480 08564-60009
A7 5086-7885 0 1 SWITCHED LO DISTRIBUTION AMP 28480 5086-7885
5086-6885 REBUILT A7, EXCHANGE REQUIRED 28480 5086-6885
A8 5086-7982 1 LOW BAND MIXER 28480 5086-7982
A9 5086-7822 5 1 PORT ATTENUATOR 28480 5086-7822
A10 5086-7981 1 YIG-TUNED FILTER/MIXER (RYTHM) 28480 5086-7981
5086-6981 REBUILT AlO, EXCHANGE REQUIRED 28480 5086-6981
All 5086-7906 6 1 PORTABLE LVLD YTO 28480 5086-7906
5086-6906 REBUILT All, EXCHANGE REQUIRED 28480 5086-6906
Al3 5086-7959 1 SECOND CONVERTER 28480 5086-7959
Al4 08563-60090 9 1 FREQUENCY CONTROL ASSEMBLY* 28480 08563-60090
Al5 08563-60091 1 RF ASSEMBLY (STANDARD)* 28480 08563-60091
Standard
Al5 08563-60092 1 RF ASSEMBLY (TCXO)* 28480 08563-60092
Option 103
Al5 08563-60093 1 RF ASSEMBLY (SIG ID)* 28480 08563-60093
Option 008
Al5 08563-60092 1 RF ASSEMBLY (TCXO/SIG ID)* 28480 08563-60092
Dption 103
3ption 008
A15UlOO 5086-7806 5 1 SAMPLER 28480 5086-7806
’ These board assemblies are part of the rebuilt board exchange program. To order
a rebuilt board, use the same number as that of the new board with the exception
of the 7th digit which should be a 9. Example: New board number is 08562-60094.
Therefore, the rebuilt board number will be 08562-69094.
Replaceable Parts 5-9
