HP 8562E

HP 85629B Test and Adjustment Module
When attached to the rear panel of the spectrum amdyzer, the HP 85629B test and
adjustment module (TAM) provides diagnostic functions for the HP 85623. The TAM is
accessed by a computer running interface software; this software is supplied with Option 915,
add Service Documentation. The TAM measures voltages at key points in the circuitry and
flags a failure whenever the voltage falls outside the limits. The TAM locates the failure
to a small functional area, which can then be examined manually. See chapter 7, “General
Troubleshooting,”
for a complete description of how to use the TAM and its interface
software.
General Information l-3
