Index
1
100 MHz oscillator, 11-16
10.6952 MHz VCXO troubleshooting, 9-18
10.7 MHz and 4.8 kHz IF filter troubleshooting,
9-18
10.7 MHz IF filter troubleshooting, 9-17
10 kHz and 3 kHz resolution bandwidth problems,
9-30
10 MHz reference
frequency response adjustment software, 3-4
10 MHz reference adjustment
OCXO, 2-48
TCXO, 2-51
1 MHz resolution bandwidth problems, 9-29
3
300 Hz to 3 kHz resolution bandwidth problems,
9-34
30 kHz resolution bandwidth problems, 9-30
3 kHz and 10 kHz resolution bandwidth problems,
9-30
4
4.8 kHz and 10.7 MHz IF filter troubleshooting,
9-18
4.8 kHz IF filter troubleshooting, 9-17
A
A10 YIG-tuned filter/mixer (RYTHM)
removal and replacement, 4-34
All YTO
removal and replacement, 4-35
Al3 second converter
removal and replacement, 4-36
Al4 and Al5 RF assembly removal, 4-37
Al4 and Al5 RF assembly replacement, 4-38
Al6 fast ADC driver
removal and replacement, 4-40
Al7 CRT driver
removal and replacement, 4-40
AlA RPG
removal and replacement, 4-14
A21 OCXO removal and replacement, 4-56
A2, A3, A4, and A5
removal, 4-15
replacement, 4- 16
A4 cal oscillator. See cal oscillator
A4 linear amplifier failures, 9-14
A4 log amplifier troubleshooting, 9-13
A5 IF assembly problems, 9-21
A5 IF section. See IF section
A6 power supply
removal, 4-21
replacement, 4-22
A7 first LO distribution amplifier
removal and replacement, 4-30
A8 low band mixer
removal and replacement, 4-31
A9 input attenuator
removal and replacement, 4-32
abbreviations, 5-2
accessories , 5-7
access to internal assemblies, 4-2
ADC/interface check, 7-14
ADC/interface section, 7-49
ADC troubleshooting, 8-21
Add File softkey, 3-12
addresses
frequency response adjustment software, 3-7
addresses of sales and service offices, 1-16
adjustment
adjustable components table, 2-5
factory selected components, 2-8
front end Cal, 2-12
related adjustments table, 2-3
safety considerations, 2-2
TAM and corresponding manual adjustments,
2-10
TAM test equipment information, 2-9
TAM test equipment list, 2-11
tools , 2-3
using TAM, 2-9
adjustment descriptions, 3-14
frequency response, 3- 14
front end Cal, 3-14
adjustment procedures, 2-1-11
10 MHz reference adjustment, OCXO, 2-48
10 MHz reference adjustment, TCXO, 2-51
calibrator amplitude adjustment, 2-47
cal oscillator amplitude, 2-26
DC log amplifiers, 2-30
Index-l
