Chapter 5, Advanced Operations
Status Reporting
Table 17 shows the Operation Status Register Group Condition Register bit assignments.
Table 17 Operation Status Register Group Condition Register Bit Assignments
Bit Number
Binary
Weighting
Condition Comment
15 32768 Not Used (Always 0) Defined by SCPI Version 1994.0
14 16384 IBASIC Program Running 1 = an IBASIC program is running on
the built-in IBASIC controller.
13 8192 Unused in the Test Set
12 4096 Unused in the Test Set
11 2048 Unused in the Test Set
10 1024 Unused in the Test Set
9 512 Call Processing Status Register
Group Summary Message
1 = one or more of the enabled events
have occurred since the last reading or
clearing of the Event Register.
8 256 Unused in the Test Set
7 128 Unused in the Test Set
6 64 Unused in the Test Set
5 32 Unused in the Test Set
4 16 Unused in the Test Set
3 8 Unused in the Test Set
2 4 Unused in the Test Set
1 2 Unused in the Test Set
0 1 Unused in the Test Set
