Chapter 5, Advanced Operations
Status Reporting
Table 20 details the Calibration Status Register Group’s Condition Register bit
assignments.
Table 21 Calibration Status Register Group, Condition Register Bit Assignments
Bit
Number
Binary
Weighting
Condition Comment
15 32768 Not Used (Always 0) Defined by SCPI Version 1994.0
14 16384 Unused in Test Set
13 8192 Unused in Test Set
12 4096 Unused in Test Set
11 2048 Unused in Test Set
10 1024 Unused in Test Set
9 512 Unused in Test Set
8 256 Unused in Test Set
7 128 Unused in Test Set
664Unused in Test Set
532Unused in Test Set
4 16 TX Power Auto-Zero Failed
3 8 Voltmeter Self-Calibration Failed
2 4 Counter Self-Calibration Failed
1 2 Sampler Self-Calibration Failed
0 1 Spectrum Analyzer Self-Calibration Failed
