308
Chapter 5, Advanced Operations
Status Reporting
Table 24
shows the Communicate Status Register Group’s Condition Register bit
assignments.
Table 24 Communicate Status Register Group, Condition Register Bit Assignments
Bit Number
Binary
Weighting
Condition Comment
15 32768 Not Used (Always 0) Defined by SCPI Version 1994.0
14 16384 Unused in Test Set
13 8192 Unused in Test Set
12 4096 Unused in Test Set
11 2048 Unused in Test Set
10 1024 Unused in Test Set
9 512 Unused in Test Set
8 256 Unused in Test Set
7 128 Unused in Test Set
6 64 Unused in Test Set
5 32 Unused in Test Set
4 16 Unused in Test Set
3 8 Unused in Test Set
2 4 Unused in Test Set
1 2 Top Box TX DSP Analyzer
Communication Channel Failure
0 1 Top Box RX DSP Analyzer
Communication Channel Failure
