386
Chapter 7, IBASIC Controller
Interfacing to the IBASIC Controller using Serial Ports
Figure 25 Available HP RS-232 Serial Cables and Adapters
Cable with Connectors Test Set to printer
or terminal
6-pin RJ-11 (male) to 25-pin DB-25
(male); 3-meter cable
08921-61039
RJ-11 to DB-25 Adapter Use with long
cable 98642-66508.
6-pin RJ-11 (female) to 25-pin DB-25
(male) Adapter
98642-66508
Cable with Connectors Long Cable from
Test Set to PC or
printer (use with
98642-66508)
6-pin RJ-11 (male) to 6-pin RJ-11 (male);
15-meter cable
98642-66505
Table 38 Available HP RS232 Serial Cables and Adapters
Device
(for RS232 Serial
connections)
Typical Uses Description
HP Part
Number
08921-61038
08921-61039
98642-66508
08921-61031
98642-66505
6-pin RJ-11
Male
9-pin DB-9
Female
6-pin RJ-11
Male
6-pin RJ-11
Male
6-pin RJ-11
Male
6-pin RJ-11
Male
25-pin DB-25 Male
Dual 6-pin RJ-11
Female
6-pin RJ-11 Femal
e
(in back of adapter
)
25-pin
DB-25
Male
3 Meter Cable
15 Meter Cable
0.6 Meter Cable
DUT
To the
Test Set
To
Computer
To the
Test Set
To Device-Under-Test
A,B, or
D plus E
D
To
Computer
A, B, or
D plus E
C
(Usable Serial Port 9 ONLY)
(Usable Serial Port 9 ONLY)
(Usable Serial Port 9 ONLY)
A
D
E
C
B
2 Meter Cable
ch6drw3.ds4
