Specifications
Calibration period: one year minimum. Specifications apply at 23° C ± 5° C, < 80% RH
Accuracy = ± (% of reading + number of digits).
Temperature Coefficient = Accuracy X 0.1/° C (-10° C to 18° C; 28° C to 55° C)
General
Do not expose product to moisture or rain. Do not use product in flammable atmosphere.
Operating Temperature: -10° to 50°C.
Humidity: 0°C to 40°C / 80% RH max, 40°C to 50°C / 70% RH max (no condensation).
Storage Temperature: -25° to 60°C / 70% RH max (no condensation).
Display reading rate: Approximately 2.3 times/second (Frequency 1/second)
Bargraph reading rate: Approximately 23 times/second
Battery life: Approximately 1000 hours
DC Voltage
Range Resolution Accuracy Input Resistance
400 mV
100 µV
± (0.3% + 1)
10 MΩ
4.0 V 1 mV
11 MΩ (nominal)
40 V 10 mV
10 MΩ (nominal)
400 V 100 mV
1000 V 1 V
Normal Mode Rejection Ratio (NMR): > 60 dB @ 50 or 60 Hz
Effective Common Mode Rejection Ratio (CMR) 1 k Ω imbalance: > 120 dB @ 50 or 60 Hz
1-17
