2-3. G BOARD REMOVAL
Open the G block in the direction
of the arrow . and remove of
the arrow .
Two screws
(+ BVTT 4 x 8)
Three hooks
Two screws
(+BVTP 3 x 10)
G shield
G board
B
A
Two printed circuit board holders
A
B
1
7
Screw
(+ BVTT 4 x 8)
3
2
4
5
6
2-4. A BOARD REMOVAL
A borad Three screws
(+BVTT 4 x 8)
