2-3
A4576
2-5. L BOARD REMOVAL
L board
Four printed circuit board holders
1
2
CN5001
CN5002
CN5004
CN5003
2-6. I/O TERMINAL BOARD REMOVAL
Three screws
(+ BVTT 3 x 8)
1
I/O terminal board assy
2
CN511
CN401
CN402
