REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
NOTE:
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
• CAPACITORS
MF : µF
• COILS
UH : µH
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A
* 8-933-275-00 A BOARD, COMPLETE
****************************
4-382-854-11 SCREW (M3X10), P, SW (+) (IC403)
<CAPACITOR>
C101 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C102 1-104-664-11 ELECT 47MF 20% 25V
C103 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C104 1-104-664-11 ELECT 47MF 20% 25V
C105 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C106 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C107 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C108 1-107-903-11 ELECT 2.2MF 20% 50V
C109 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C110 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C111 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C112 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C115 1-104-514-11 FILM 0.22MF 10% 250V
C120 1-107-949-11 ELECT 2.2MF 20% 200V
C121 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C122 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C127 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C130 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C201 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C202 1-104-664-11 ELECT 47MF 20% 25V
C203 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C204 1-104-664-11 ELECT 47MF 20% 25V
C205 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C206 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C207 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C208 1-107-903-11 ELECT 2.2MF 20% 50V
C209 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C210 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C211 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C212 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C215 1-104-514-11 FILM 0.22MF 10% 250V
C217 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C220 1-107-949-11 ELECT 2.2MF 20% 200V
C221 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C222 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C230 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C301 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C302 1-104-664-11 ELECT 47MF 20% 25V
C303 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C304 1-104-664-11 ELECT 47MF 20% 25V
C305 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C306 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C307 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C308 1-107-903-11 ELECT 2.2MF 20% 50V
C309 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C310 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C311 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C312 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C315 1-104-514-11 FILM 0.22MF 10% 250V
C317 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C319 1-107-888-11 ELECT 47MF 20% 25V
C320 1-107-949-11 ELECT 2.2MF 20% 200V
C321 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C322 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C330 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C401 1-126-964-11 ELECT 10MF 20% 50V
C402 1-104-664-11 ELECT 47MF 20% 25V
C403 1-104-664-11 ELECT 47MF 20% 25V
C404 1-126-964-11 ELECT 10MF 20% 50V
C405 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C407 1-126-964-11 ELECT 10MF 20% 50V
C408 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C409 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C410 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C412 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C414 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C415 1-128-562-11 ELECT 47MF 20% 100V
C416 1-104-664-11 ELECT 47MF 20% 25V
C417 1-115-349-51 CERAMIC 0.01MF 2KV
C419 1-162-318-11 CERAMIC 0.001MF 10% 500V
C420 1-126-967-11 ELECT 47MF 20% 50V
C421 1-126-964-11 ELECT 10MF 20% 50V
C424 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C429 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C431 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C434 1-162-318-11 CERAMIC 0.001MF 10% 500V
C435 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C436 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C438 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
7-1
