REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
<IC LINK>
PS401¡1-533-590-31LINK, IC (1A/90V AC, 60V DC)
<TRANSISTOR>
Q101 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q105 8-729-041-66 TRANSISTOR 2SC4015TV2
Q106 8-729-200-17 TRANSISTOR 2SA1091-O
Q201 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q202 8-729-107-31 TRANSISTOR 2SC3545-T43
Q205 8-729-041-66 TRANSISTOR 2SC4015TV2
Q206 8-729-200-17 TRANSISTOR 2SA1091-O
Q301 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q305 8-729-041-66 TRANSISTOR 2SC4015TV2
Q306 8-729-200-17 TRANSISTOR 2SA1091-O
Q401 8-729-216-22 TRANSISTOR 2SA1162-G
Q402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q403 8-729-216-22 TRANSISTOR 2SA1162-G
Q404 8-729-901-00 TRANSISTOR DTC124EK
Q405 8-729-216-22 TRANSISTOR 2SA1162-G
Q406 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q407 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q408 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q409 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q410 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
<RESISTOR>
R101 1-215-395-00 METAL 82 1% 1/4W
R102 1-216-025-91 RES, CHIP 100
R103 1-215-395-00 METAL 82 1% 1/4W
R104 1-216-025-91 RES, CHIP 100
R105 1-216-021-00 RES, CHIP 68
R106 1-216-019-00 RES, CHIP 56
R108 1-216-099-00 RES, CHIP 120K
R109 1-216-107-00 RES, CHIP 270K
R110 1-216-295-91 SHORT 0
R111 1-216-049-91 RES, CHIP 1.0K
R112 1-216-619-11 METAL CHIP 47 0.50%1/10W
R113 1-216-009-00 RES, CHIP 22
R114 1-216-035-00 RES, CHIP 270
R115 1-216-035-00 RES, CHIP 270
R116 1-216-017-91 RES, CHIP 47
R117 1-216-063-91 RES, CHIP 3.9K
R118 1-216-057-00 RES, CHIP 2.2K
R119 1-216-015-00 RES, CHIP 39
R120 1-216-097-91 RES, CHIP 100K
R121 1-216-097-91 RES, CHIP 100K
R122 1-216-027-00 RES, CHIP 120
R123 1-216-027-00 RES, CHIP 120
R124 1-219-497-11 CARBON 22 5% 1/2W
R125 1-216-693-11 METAL CHIP 56K 0.50%1/10W
R126 1-216-097-91 RES, CHIP 100K
R127 1-216-035-00 RES, CHIP 270
R128 1-216-121-91 RES, CHIP 1.0M
R129 1-218-776-11 METAL CHIP 1M 0.50%1/10W
R130 1-216-097-91 RES, CHIP 100K
R131 1-216-057-00 RES, CHIP 2.2K
R132 1-216-035-00 RES, CHIP 270
R133 1-216-049-91 RES, CHIP 1.0K
R134 1-216-097-91 RES, CHIP 100K
R135 1-216-037-00 RES, CHIP 330
R136 1-216-097-91 RES, CHIP 100K
R137 1-216-097-91 RES, CHIP 100K
R138 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R139 1-216-073-00 RES, CHIP 10K
R140 1-216-129-00 RES, CHIP 2.2M
R141 1-216-025-91 RES, CHIP 100
R142 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R144 1-216-295-91 SHORT 0
R167 1-216-121-91 RES, CHIP 1.0M
R201 1-215-395-00 METAL 82 1% 1/4W
R202 1-216-025-91 RES, CHIP 100
R203 1-215-395-00 METAL 82 1% 1/4W
R204 1-216-025-91 RES, CHIP 100
R205 1-216-021-00 RES, CHIP 68
R206 1-216-015-00 RES, CHIP 39
R208 1-216-099-00 RES, CHIP 120K
R209 1-216-107-00 RES, CHIP 270K
R210 1-216-295-91 SHORT 0
R211 1-216-049-91 RES, CHIP 1.0K
R212 1-216-619-11 METAL CHIP 47 0.50%1/10W
R213 1-216-009-00 RES, CHIP 22
R214 1-216-035-00 RES, CHIP 270
R215 1-216-035-00 RES, CHIP 270
R216 1-216-017-91 RES, CHIP 47
R217 1-216-063-91 RES, CHIP 3.9K
R218 1-216-057-00 RES, CHIP 2.2K
R219 1-216-015-00 RES, CHIP 39
R220 1-216-097-91 RES, CHIP 100K
R221 1-216-097-91 RES, CHIP 100K
R222 1-216-027-00 RES, CHIP 120
R223 1-216-027-00 RES, CHIP 120
R224 1-219-497-11 CARBON 22 5% 1/2W
R225 1-216-693-11 METAL CHIP 56K 0.50%1/10W
R226 1-216-097-91 RES, CHIP 100K
R227 1-216-035-00 RES, CHIP 270
R228 1-216-121-91 RES, CHIP 1.0M
R229 1-218-776-11 METAL CHIP 1M 0.50%1/10W
R230 1-216-097-91 RES, CHIP 100K
R231 1-216-057-00 RES, CHIP 2.2K
R232 1-216-035-00 RES, CHIP 270
R233 1-216-049-91 RES, CHIP 1.0K
R234 1-216-097-91 RES, CHIP 100K
R235 1-216-037-00 RES, CHIP 330
R236 1-216-097-91 RES, CHIP 100K
R237 1-216-097-91 RES, CHIP 100K
R238 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R239 1-216-073-00 RES, CHIP 10K
R240 1-216-129-00 RES, CHIP 2.2M
R241 1-216-025-91 RES, CHIP 100
R242 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
A
7-3
