HP A4576

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
A4576
IC701 8-759-822-38 IC LA6510
IC702 8-759-444-82 IC LA7841L
IC703 8-759-100-96 IC UPC4558G2
IC901 8-759-467-70 IC BA9756FS-E2
<CHIP CONDUCTOR>
JR001 1-216-295-91 SHORT 0
JR002 1-216-295-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR004 1-216-295-91 SHORT 0
<COIL>
L001 1-406-665-11 COIL, CHOKE 100UH
L002 1-406-665-11 COIL, CHOKE 100UH
L003 1-412-537-31 INDUCTOR 100UH
L004 1-412-537-31 INDUCTOR 100UH
L006 1-410-482-31 INDUCTOR 100UH
L007 1-412-537-31 INDUCTOR 100UH
L008 1-412-537-31 INDUCTOR 100UH
L501 1-412-537-31 INDUCTOR 100UH
L502 1-406-671-11 COIL, CHOKE 1.0MMH
L503 1-416-455-11 COIL, HORIZONTAL LINEARITY
L504 1-416-456-11 COIL, HORIZONTAL LINEARITY
L505 1-406-675-11 COIL, CHOKE 4.7MMH
L507 1-406-675-11 COIL, CHOKE 4.7MMH
L701 1-412-537-31 INDUCTOR 100UH
L702 1-412-522-41 INDUCTOR 5.6UH
L901 1-412-537-31 INDUCTOR 100UH
L902 1-406-660-41 COIL, CHOKE 15UH
L903 1-412-537-31 INDUCTOR 100UH
<IC LINK>
PS501¡1-533-592-31LINK, IC (1.6A/90V AC, 60V DC)
PS502¡1-532-984-91LINK, IC (2A/90V)
PS503¡1-532-984-91LINK, IC (2A/90V)
PS504¡1-532-984-91LINK, IC (2A/90V)
PS701¡1-533-590-31LINK, IC (1A/90V AC, 60V DC)
PS901¡1-533-592-31LINK, IC (1.6A/90V AC, 60V DC)
<TRANSISTOR>
Q001 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q003 8-729-216-22 TRANSISTOR 2SA1162-G
Q004 8-729-216-22 TRANSISTOR 2SA1162-G
Q005 8-729-216-22 TRANSISTOR 2SA1162-G
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q007 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q503 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q504 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q505 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q506 8-729-820-73 TRANSISTOR 2SC3746
Q507 8-729-035-54 TRANSISTOR 2SJ449
Q508 8-729-031-87 TRANSISTOR 2SC5047-CA
Q509 8-729-033-25 TRANSISTOR DTC114GKA
Q510 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q511 8-729-140-50 TRANSISTOR 2SC3209LK
Q512 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q513 8-729-901-00 TRANSISTOR DTC124EK
Q517 8-729-216-22 TRANSISTOR 2SA1162-G
Q522 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q523 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q524 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q525 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q526 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q527 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q528 8-729-042-43 TRANSISTOR 2SK2098-01MR
Q660 8-729-033-26 TRANSISTOR DTA114GKAT146
Q661 8-729-033-25 TRANSISTOR DTC114GKA
Q701 8-729-800-32 TRANSISTOR 2SC2362K-G
Q703 8-729-178-43 TRANSISTOR 2SC2784-E
Q704 8-729-207-82 TRANSISTOR 2SC3421-Y
Q705 8-729-204-91 TRANSISTOR 2SA1049-GR
Q706 8-729-207-89 TRANSISTOR 2SA1358-Y
Q707 8-729-216-22 TRANSISTOR 2SA1162-G
Q708 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
Q901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q902 8-729-216-22 TRANSISTOR 2SA1162-G
Q904 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q905 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q908 8-729-035-54 TRANSISTOR 2SJ449
Q909 8-729-033-91 TRANSISTOR 2SK1120LBSONY2
<RESISTOR>
R001 1-216-025-91 RES, CHIP 100
R002 1-216-049-91 RES, CHIP 1.0K
R003 1-216-049-91 RES, CHIP 1.0K
R004 1-216-049-91 RES, CHIP 1.0K
R005 1-216-073-00 RES, CHIP 10K
R006 1-216-049-91 RES, CHIP 1.0K
R007 1-216-025-91 RES, CHIP 100
R008 1-216-089-91 RES, CHIP 47K
R009 1-216-025-91 RES, CHIP 100
R010 1-216-081-00 RES, CHIP 22K
R011 1-216-097-91 RES, CHIP 100K
R012 1-216-025-91 RES, CHIP 100
R013 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R016 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R017 1-216-049-91 RES, CHIP 1.0K
R018 1-216-049-91 RES, CHIP 1.0K
R019 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R020 1-216-049-91 RES, CHIP 1.0K
R023 1-216-025-91 RES, CHIP 100
R024 1-216-089-91 RES, CHIP 47K
R026 1-216-073-00 RES, CHIP 10K
D
7-11
