Appendix D
Remove/Replace Flexible Disk Drives
Replacing the Flexible Disk Drive
108
3. Route the SCSI cable over the exposed edges of the I/O cards as shown in Figure D-19. Grasp hold
of the PCI cage handle and install the PCI cage in the workstation.
Figure D-19 Routing the SCSI Cable and Installing the PCI Cage
PCI Cage Handle
PCI Cage
SCSI Cable
PCI Cage Cover
I/O Cards
