HP 2740 Ultra-Slim Expansion Base
Top Components
Docking posts (2)
Align and secure the computer for proper connection to the docking station
Computer connect/
release mechanisms (2)
Connect and release the computer when you press the connect button
Docking connector
Docking connector for notebook or travel battery
Connect button
Secures and releases the computer
Slide in to secure the computer
Slide out to release the computer
LEDs
AC present: aqua white; Dock connected: blue; two RJ45 LEDs: amber/green
Rear/Right-Side Components
AC power port
Energy-efficient 65W Smart AC adapter features integrated surge protection to help against power
fluctuations.
Optical drive
9.5mm PATA DVD +/-RW Optical drive
Integrated cable lock slot
Supports the HP Docking Station Cable Lock with a simplified locking mechanism. Gives you two security
options: lock the docking station only (which also prevents access to the Station drive bay); or lock both
the docking station and your notebook for additional security.
Also supports an industry standard notebook lock.
Network connectors
RJ-45 / Ethernet pass thru
USB ports
3 USB 2.0 ports
Audio connectors
Headphone output (stereo); microphone input (stereo)
Other connectors
VGA, DisplayPort 1.1, eSATA
QuickSpecs
HP Ultra-light Docking Stations
Overview
DA - 13639 North America — Version 9 — November 20, 2013
Page 8
