Product walkaround
Front view
1
14
15
13
2
4
5
6
7
8
9
3
12
11
10
1 Color control panel
2 Document-feeder top-cover (lift open to clear jams)
3 Automatic document-feeder (ADF)
4 Document-feeder output bin
5 Scanner lid
6 Convenience stapler (only for the HP Color LaserJet CM3530fs MFP)
7 Right-side door (access for clearing jams)
8 Tray 1 (pull the handle to open the tray)
9 Lower-right door
10 On/off button
11 Optional Tray 3
12 Tray 2
13 Front door (access to print cartridges and toner collection unit)
14 Standard output bin
15 Hardware integration port
4 Chapter 1 Product basics ENWW
