10. Remove the six Torx T8M2.5×6.0 screws (1) that secure the display panel to the display

enclosure.

11. Remove the display panel (2).

12. Remove the four Phillips PM2.0×3.0 screws (1) that secure each display hinge to the display panel.

13. Remove the display hinges (2).

NOTE: The left and right display hinges are available using spare part number 447204-001.

Reverse this procedure to install the display assembly.

Top cover

Description Spare part number

Top cover (includes TouchPad, TouchPad cable, and fingerprint reader) 443921-001

Component replacement procedures 79
