HP Compaq d530 MT - Page 54

A–2 www.hp.com Hardware Reference Guide
Specifications
Heat Dissipation
Maximum
Typical (idle)
1,260 BTU/hr
256 BTU/hr
318 kg-cal/hr
65 kg-cal/hr
Power Supply
Operating Voltage Range
Rated Voltage Range*
Rated Line Frequency
115 V
90-132 VAC
100-127 VAC
50-60 Hz
230V
180-264 VAC
200-240 VAC
50-60 Hz
Power Output 240 W 240 W
Rated Input Current (maximum)* 6A @ 100VAC 3A @ 200VAC
*This system utilizes a passive power factor corrected power supply when used in the 230V
mode. This allows the system to pass the CE mark requirements for use in the countries of the
European Union.
HP Compaq d530 Convertible Minitower (Continued)
