2-6 www.hp.com Hardware Reference Guide
Hardware Upgrades
6. To remove the front bezel, gently pull up all three tabs 1 on the
top of the bezel, then pull the bezel 2 away from the chassis.
Removing the Front Bezel
To reassemble the computer, reverse the above procedure.
✎
Press down while replacing the access panel. Refer to the label on the
inside of the access panel for more information.
✎
To re-install the front bezel, insert the two bezel bottom tabs, then
rotate the front bezel forward to snap the three tabs on the top of the
bezel in place.
