automatically create an html file that has the same appearance as the information displayed on the
screen.
1. Insert a diskette or USB 2.0 HP Drive Key (capacity must be 64MB or higher). USB 1.0 Drive Keys
are not supported.
2. Click Save in the bottom right corner of the screen.
3. Select Save to the floppy or Save to USB key.
4. Enter a file name in the File Name box and click the Save button. An html file will be saved to the
inserted diskette or USB HP Drive Key.
NOTE Do not remove the diskette or USB key until you see a message indicating that the
html file has been written to the media.
5. Print the information from the storage device used to save it.
NOTE To exit HP Insight Diagnostics, click the Exit Diagnostics button in the bottom left corner
of the screen then remove the Documentation and Diagnostics CD from the optical drive.
Downloading the Latest Version of HP Insight Diagnostics
1. Go to http://www.hp.com.
2. Click the Software & Driver Downloads link.
3. Enter your product number (for example, dc5750) in the text box and press the Enter key.
4. Select your specific computer model.
5. Select your OS.
6. Click the Diagnostic link.
7. Click HP Insight Diagnostics Offline Edition.
8. Select a language and click Download.
NOTE The download includes instructions on how to create the bootable CD.
Protecting the Software
To protect software from loss or damage, you should keep a backup copy of all system software,
applications, and related files stored on the hard drive. See the operating system or backup utility
documentation for instructions on making backup copies of data files.
ENWW Protecting the Software 5

Other manuals for HP Compaq dc5750 MT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq dc5750 MT and is the answer not in the manual?

HP Compaq dc5750 MT Specifications

General IconGeneral
ChipsetATI Radeon Xpress 1150
MemoryUp to 4 GB DDR2 SDRAM
NetworkIntegrated Broadcom NetXtreme Gigabit Ethernet
AudioIntegrated High Definition audio
Power Supply300W
ProcessorAMD Athlon 64 X2, AMD Athlon 64, AMD Sempron
GraphicsIntegrated ATI Radeon Xpress 1150 or optional discrete graphics
Optical DriveDVD-ROM, DVD+/-RW
Expansion Slots1 PCI Express x16
Ports1 serial, 1 parallel, 2 PS/2, 1 VGA, 1 audio in, 1 audio out
Operating SystemWindows XP Professional
Dimensions16.5 inches
StorageSATA Hard Drive
