HP Compaq dc5750 MT Troubleshooting Guide

Restoring the Software
The HP Backup and Recovery Manager is an easy-to-use, versatile application that is pre-loaded on
each system and allows you to:
●
create Recovery Points to back up the entire system incrementally
●
back up the entire hard drive in a single archive
●
back up individual files
Backups can be scheduled to occur automatically at designated intervals, or they can be initiated
manually. Recovery can be performed from the Recovery Partition on the hard drive or the Recovery
Disc Set. The Recovery Disc Set includes the Restore Plus! CD, the Microsoft Operating System, and
any Supplemental Software CDs.
NOTE HP highly recommends that you create a Recovery Disc Set immediately before using
the computer and schedule regular automatic Recovery Point backups.
The HP Backup and Recovery Manager provides two basic recovery methods. The first, recovery of
files and folders, operates in Windows. The second, PC Recovery, requires a reboot to the Recovery
Partition or from the Recovery Disc Set. To reboot to the Recovery Partition, press F11 at startup when
you see the message “Press F11 for Emergency Recovery.”
NOTE For more information on using HP Backup and Recovery Manager, refer to the HP
Backup and Recovery Manager User Guide by selecting Start > HP Backup and Recovery >
HP Backup and Recovery Manager Manual.
6 Chapter 1 Computer Diagnostic Features ENWW

HP Compaq dc5750 MT Specifications

General

Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Audio	Integrated High Definition audio
Power Supply	300W
Processor	AMD Athlon 64 X2, AMD Athlon 64, AMD Sempron
Graphics	Integrated ATI Radeon Xpress 1150 or optional discrete graphics
Optical Drive	DVD-ROM, DVD+/-RW
Expansion Slots	1 PCI Express x16
Ports	1 serial, 1 parallel, 2 PS/2, 1 VGA, 1 audio in, 1 audio out
Operating System	Windows XP Professional
Dimensions	16.5 inches
Storage	SATA Hard Drive
