HP Compaq dc7700 MT User Manual

7. Install two guide screws in the lower holes on each side of the drive (1).
NOTE Optical drives, diskette drives, and media card readers use M3 metric guide screws.
Eight extra metric guide screws are provided on the diskette drive bracket under the access
panel. The HP-supplied metric screws are black.
Figure 2-19 Installing a 5.25-Inch Drive in a Minitower (top) and Desktop (bottom)
8. Install the drive in the desired drive bay by sliding it all the way into the front of the drive cage until
it locks (2). The drivelock automatically secures the drive in the bay.
CAUTION The bottom 5.25-inch drive bay has a shorter depth than the upper two bays.
The bottom bay supports a drive that is no more than 17 cm (6.7 inches) in depth, including
the cables that attach to the back of the drive. Do not try to force a larger drive, such as an
optical drive, into the bottom bay. This could cause damage to the drive and the system
board. The use of unnecessary force when installing any drive into the drive bay may result
in damage to the drive.
NOTE If you are installing a third optional drive, you may need to remove the strap that
bundles the extra power connectors.
ENWW Installing Additional Drives 31

HP Compaq dc7700 MT Specifications

General

Chipset	Intel Q965 Express
Memory	Up to 8 GB DDR2 SDRAM
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Processor	Intel Core 2 Duo, Intel Pentium D, Intel Pentium 4
Storage	80GB to 500GB SATA
Graphics	Intel Graphics Media Accelerator 3000
Optical Drive	DVD-ROM, DVD+/-RW
Ports	USB 2.0, serial, parallel, VGA, audio in/out
Form Factor	Microtower
Audio	Integrated High Definition Audio
Network	Integrated 10/100/1000 Ethernet
Operating System	Windows XP, Windows Vista
Power Supply	365W
