Access panel
The computer has one main rear access panel that allows access to internal components.
To remove the access panel:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 38).
2. Slide the access panel latches toward the edges of the unit, then slide the access panel toward
the top of the computer until it slides off the unit.
Figure 7-6 Removing the access panel
42 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
