HP Compaq Elite 8300 User Manual

Hood sensor
The hood sensor is located on the bottom left of the computer (when viewed from behind).
Figure 7-85 Hood sensor location
To remove the hood sensor:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 38).
2. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 38).
3. Remove the access panel (see
Access panel on page 42).
4. Remove the stand (see
Stand on page 44).
5. Remove the lower panel (see
Lower panel on page 46).
6. Remove the side panels (see
Side panels on page 84).
7. Remove the metal plate (see
Metal plate on page 47).
8. Remove the power supply (see
Power supply on page 86).
9. Remove the system board (see
System board on page 89).
10. Remove the front bezel (see
Front bezel on page 100).
11. Remove the display panel (see
Display panel on page 105).
12. Disconnect the hood sensor cable from the system board connector labeled HSENSE.
Hood sensor 111

HP Compaq Elite 8300 Specifications

General

Operating temperature (T-T)	10 - 35 °C
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
HDD size	3.5 \
Dimensions (WxDxH)	178 x 445 x 448 mm
Microphone in	Yes
HDMI ports quantity	0
PS/2 ports quantity	2
USB 2.0 ports quantity	6
PCI slots	3
Chassis type	Mini-Tower
Product type	PC barebone
Product color	Gray
Audio system	HD
Motherboard chipset	Intel® Q77 Express
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Power supply	320 W
Operating system installed	No
Processor model	-
Processor family	Intel

Weight and Dimensions

Weight	11200 g
