HP Compaq NC6110

Removal and Replacement Procedures
Maintenance and Service Guide 6–3
Section Description
# of Screws Removed
6.10 Keyboard 2
6.11 Switch Cover 2
6.12 LED Board 4
6.13 Fan 2 loosened
6.14 Heat Sink 4 loosened
6.15 Processor 1 loosened
6.16 Modem Board 2
6.17 Internal Memory Module 0
6.18 RTC Battery 0
6.19 Display Assembly 6
6.20 Top C ove r 15
6.21 Speaker 4
6.22 Digital Media Board 0
6.23 USB/Audio Board 1
6.24 System Board 1 screw
4 screw locks on
HP
Compaq nc6110 and
nc6120 models
2 screw locks on
HP
Compaq nx6110 and
nx6120 models
6.25 Serial Connector Module 2 screw locks
Disassembly Sequence Chart (Continued)
