6–36 Maintenance and Service Guide
Removal and Replacement Procedures
6.19 Display Assembly
1. Prepare the computer for disassembly (Section 6.3).
2. Remove the Memory module/Mini PCI compartment cover
(
Section 6.7) and disconnect the wireless antenna cables from
the Mini PCI communications module (Section 6.8).
3. Remove the keyboard (Section 6.10).
4. Remove the switch cover (Section 6.11)
Display Assembly Spare Part Number Information
15.0-inch, SXGA+WVA, TFT
15.0-inch, XGA, TFT
14.1-inch, XGA, TFT
378210-001
378209-001
378208-001
To Next Page
