Screw Listing
Maintenance and Service Guide C–5
Torx8 T8M2.0×9.0 Screw Location
Table C-4
Torx8 T8M2.0×9.0 Screw
Color Qty. Length Thread
Head
Width
Black 24 9.0 mm 2.0 mm 4.0 mm
Where used:
One screw that secures the optical drive to the computer (documented in
Section 6.9)
mm
