HP Compaq NC6110

C–12 Maintenance and Service Guide
Screw Listing
Phillips PM1.5×4.0 Screw Locations
Table C-6
Phillips PM1.5×4.0 Screw
Color Qty. Length Thread
Head
Width
Silver 4 4.0 mm 1.5 mm 4.0 mm
Where used:
4 screws that secure the LED board to the switch cover (documented in
Section 6.12)
mm
