HP Compaq NC6110

Screw Listing
Maintenance and Service Guide C–17
Torx8 T8M2.0×4.0 Screw Location
Table C-10
Torx8 T8M2.0×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 6 4.0 mm 2.0 mm 4.0 mm
Where used:
One screw that secures the USB/audio board the computer (documented in
Section 6.23)
mm
